Revolabs Executive HD ™ Indicator LEDs
The following tables show activities associated with the various states shown by the LEDs:
Equipment Use
Microphone in Charger
Base
Microphone not in
Charger Base
Microphone LED
Solid RED
Solid GREEN
OFF
Two RED flashes
every 1.5 seconds
GREEN flash every
1.5 seconds
Solid RED
Alternating slow
GREEN and RED
YELLOW flash
alternating with
GREEN
YELLOW flash
alternating with two
RED flashes
Alternating RED,
YELLOW, GREEN
Rapid RED flashes
continuing for more
than a few seconds
Groups of five rapid
RED flashes
Base Station
Channel LEDs
OFF
OFF
OFF
Two RED flashes
every 1.5 seconds
GREEN flash every
1.5 seconds
Solid RED
Alternating slow
GREEN and RED
GREEN Flashing
RED Flashing
OFF
OFF
OFF
- 32 -
Meaning
Charging in Progress
Charging Complete
Microphone powered OFF or
battery discharged
Microphone paired and muted
Microphone paired and ―live‖
Pairing mode or confirmation of
powering-down.
Microphone or channel not
paired
Microphone low battery
(mic live)
Microphone low battery
(mic muted)
Searching for a connection, or
out of radio range. The
Microphone will try to re-
establish the link for about 15
minutes, and then turn off
automatically.
Radio congestion – it is not
possible to make a radio
connection because there are
already too many nearby users,
or there is heavy radio
interference. Possibilities
include some types of digital
wireless devices or other
Revolabs installations.
Unit is faulty. Contact your AV
service provider for advice.
