String Table:
The following table represents the serial syntax of the Executive HD system. Any command marked
with an asterisk will only function if the Base Station has Gold Enabled by entering that systems
unlock code. (See Revolabs HD Gold Control Panel)
Argument Command
set lock*
set mute
set mute
set gain*
get lock*
get mute
get gain*
get type*
get batt
val lock*
val mute
val gain*
val type*
val batt
Channel#
1-8 = ch 1-8
1-8 = ch 1-8
A = All Mics
1-8 = ch 1-8
1-8 = ch 1-8
1-8 = ch 1-8
A = Master Mute
1-8 = ch 1-8
1-8 = ch 1-8
1-8 = ch 1-8
1-8 = ch 1-8
1-8 = ch 1-8
A = Master Mute
1-8 = ch 1-8
1-8 = ch 1-8
1-8 = ch 1-8
- 17 -
Value
0 = Mic Lock Off
1 = Mic Lock On
0 = Unmute Mic
1 = Mute Mic
0 = Master Mute Off
1 = Master Mute On
2 = Master Mute Toggle
3 = Mute All
0 = 0db Absolute
1 = -0.5db Absolute
2 = +0.5db Absolute
80-120 = -10db - +10db in 0.5db increments
0 = Mic Lock Off
1 = Mic Lock On
0 = Unmuted
1 = Self Muted (TT Master Mute Mode)
2 = Muted
3 = Microphone Off
4 = Microphone Out of Range*
5 = Microphone Charging*
80-120 = -10db - +10db in 0.5db increments
0 = Lapel (Wearable)
1 = Tabletop Omnidirectional
2 = Tabletop Directional
3 = XLR Adapter
4 = Countryman Adapter
0 = empty
1 = 25%
2 = 50%
3 = 75%
4 = 100%
