• Mixing
• Acoustic echo cancellation (AEC)
• Feedback elimination
• Level control
• Equalization
• Noise cancellation
The system is designed to optimize audio capture/reproduction by providing:
• Consistent audio input from all participants
• Minimum room noise
• Mute control
• Wireless encryption
• Automatic channel selection
• Full duplex audio.
The Charger Base stores and charges the wireless microphones when not in use. The
Charger Base also serves as a programming station for the microphones, should firmware
updates to the microphones be required.
Installing the Revolabs Executive HD ™ Base Station
The Revolabs Executive HD ™ Base Station, shown below in front and rear panel views,
manages wireless audio signal processing, pairing, and muting between the Revolabs
microphones and the Base Station.
Front View
2
5
1
3
4
11
Rear View
7
13
12 14
8 10
6
9
