21
Excel 100T
B2
Side burner electrode
wire goes here.
22
Excel 100T
Fix the Hose Tidy (C11) onto short leg front
using a ST4.0x10 Screw (D4), then clip the
hose into hose tidy as shown.
Proceed to the next page for operation and maintenance.
Important – the barbecue must not be used before being leak tested as detailed on P. 20
Excel 200T
Connect the electrode
wire to the Igniter
Button (B2) under the
control panel.
Main burner
electrode wire
goes here.
Excel 200T
C11
ASSEMBLY IS NOW COMPLETE.
