Outback® Omega Charcoal 100 and Omega Charcoal 200 Barbecues
Omega Charcoal 100
Photographs are not to scale.
Specifications subject to change
without prior notice.
WARNING
Charcoal Barbecues
Assembly and Operating Instructions for
For outdoor use only - do not use indoors! Not for commercial use.
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
WARNING! Accessible parts may be very hot. Keep children and pets away!
CAUTION: Do not use spirit or petrol for lighting or re-lighting! Use only
firelighters complying to EN1860-3!
WARNING! This barbecue becomes very hot. Do not move it during operation!
Install this barbecue on a safe and even surface.
Any modification of the appliance, misuse, or failure to follow the instructions
may be dangerous and will invalidate your warranty. This does not affect your
statutory rights.
Retain these instructions for future reference.
Omega Charcoal 200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Omega Charcoal 100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Outback Omega Charcoal 100

  • Page 1 Charcoal Barbecues Assembly and Operating Instructions for Outback® Omega Charcoal 100 and Omega Charcoal 200 Barbecues Omega Charcoal 100 Omega Charcoal 200 Photographs are not to scale. Specifications subject to change without prior notice. • For outdoor use only - do not use indoors! Not for commercial use.
  • Page 2: Parts List

    A. Parts List Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram’. Outback® Omega Outback® Omega Code Part Charcoal 100 Charcoal 200 Hood Wood Hood Handle - Top Half...
  • Page 3: Parts Diagrams

    B. Parts Diagrams Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram.’...
  • Page 4 C1. Omega Charcoal 100 Hardware Reference Diagram Specifications subject to change without prior notice. D3, D4 D10, D11 D8, D9 D5, D6,D7...
  • Page 5 C2. Omega Charcoal 200 Hardware Reference Diagram Specifications subject to change without prior notice. D8, D9 D5, D6,D7 D10, D11 D3, D4...
  • Page 6 D. Assembly TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Philips/crosspoint screwdriver, adjustable spanner or metric spanner set Whilst every care is taken in the manufacture of this product, care must be taken during assembly in case sharp edges are present.
  • Page 7 Attach the support leg (C7) to the L/H and R/H Connect the support leg to the table using the leg legs (C4, C5)using the leg joint bolts (D10) and joint bolts (D8) and nuts (D9). nuts (D11). D3 D4 Insert the pre-installed bolts on the underside of the body (B3) into the keyhole slots in the L/H Attach the rear handle bar (C1) using the rear and R/H vents (B6, B7).
  • Page 8 Secure the barbecue body to the tops of the L/H Remove the hood handlebar bolts from the and R/H legs by threading the body bolts (D5) handlebar. Attach the hood handlebar (A4) to the through a washer (D6), the barbecue body (B3), hood (A1) by threading the handlebar bolts spacer (D7), and screwing into the tops of the through the hood and...
  • Page 9 Insert the long wire ends of the warming rack into Attach the side shelves (C2, C3) to the L/H and the corresponding holes in the barbecue body. R/H legs using the side shelf bolts (D12). Omega Charcoal 100 assembly is now Omega Charcoal 200 assembly is now complete. complete.
  • Page 10: Installation

    products as they burn too quickly in this E. Important Information design. We recommend using charcoal briquettes. Use only enough briquettes to Please read understand these cover the charcoal grill in a single layer. Do instructions before assembly and use. overload charcoal grill.
  • Page 11: Care And Maintenance

    A full range of heavy-duty wood. Outback® covers is available for all models. Do not leave the barbecue exposed to outside H6. Fixings weather conditions or stored in damp, moist All screws and bolts, etc.
  • Page 12 OUTBACK barbecues are warranted to the original purchaser against defects in materials and workmanship for a period of one (1) year from the date of purchase. OUTBACK UK will, within this period, supply replacements for defective parts free of charge provided that: ♦...
