Icom IC-F9010 SERIES Operating Manual page 9

[Home] has the following additional functions with trans-
ceivers whose revision number is 1.7 or later:
➥ While in the emergency mode, push to exit the mode.
➥ While in the APCO P25 mode, push to cancel the talk
back function.
Ext. CH Sel Mode KEY (Available on Mobile transceivers only)
Push to turn the Memory Channel Select function from an ex-
ternal input ON or OFF.
When this function is turned ON, and a signal is input from an
external unit that is connected to the D-sub 25-pin connector,
the operating channel changes to the desired memory chan-
nel. In that case, a memory channel selection with the key or
dial operation, and the microphone hanger action functions,
Move to Priority A Channel and On Hook Scan, are disabled.
When this function is turned OFF, the memory channel selec-
tion from an external input is disabled.
• This function is usable when an external unit is connected to the
transceiver.
• Ask your dealer for details of an external input.
(Simple/10-key and Non-display types operate differently)
SCRAMBLER/ENCRYPTION KEY "S/D"
- The UT-125 /
aes des encryption unit
is required for the Encryption function.
unit
❍ For Simple and 10-key types
➥ While in the analog mode, push to turn the Voice Scrambler
function ON or OFF.
➥ While in the APCO P25 mode, push to turn the Encryption
function ON or OFF.
or UT-128
des encryption
➥ While in the mixed (digital and analog) mode, push to turn
the Voice Scrambler and Encryption functions ON or OFF,
separately or simultaneously, as shown below.
Voice Scrambler and Encryption functions OFF
("OFF" appears* / " " disappears)
PUSH
Voice Scrambler function ON ("SCRM" appears* / " " appears)
PUSH
Encryption function ON ("ENC" appears* / " " appears)
PUSH
Voice Scrambler and Encryption functions ON
("SCRM/ENC" appears* / " " appears)
PUSH
❍ For Non-display types
➥ While in the analog mode, push and hold for 1 sec. to turn
the Voice Scrambler function ON. If the function is ON,
push to turn it OFF.
➥ While in the APCO P25 mode, push and hold for 1 sec.
to turn the Encryption function ON. If the function is ON,
push to turn it OFF.
➥ While in the mixed (digital and analog) mode, push and hold
for 1 sec. to turn both the Voice Scrambler and Encryption
functions ON. If the functions are ON, push to turn them
OFF.
1
PREPARATION
* Appears for about 1 sec.
☞ Continued on the next page
