4
APCO P25 MODE OPERATION
n Site Select function
(P25 Trunking mode only)
The RFSS and SITE IDs can be edited manually with
[Site Select].
Not available on Non-display types.
To edit the RFSS and SITE IDs:
q Push [Site Select] to select "SITE 1."
w Push [Site Select] again to display the site information
(RFSS ID and SITE ID).
• Push [Site Select] to return to normal operation.
e Push and hold [Site Select] for 1 sec. to enter the RFSS
ID edit mode.
r Push [CH Up]/[CH Down] or rotate [CH Up/Down] to edit
the ID.
t After editing, push [Site Select] to store the RFSS ID, and
enter the SITE ID edit mode.
y Repeat step r to edit.
u Push and hold [Site Select] for 1 sec. to return to "SITE 1"
indication as in step q.
i Push and hold [Site Select] for 1 sec. to store the SITE ID,
and return to normal operation.
29
For P25 Trunking mode operation:
The transceiver should be registered and group affiliated
with the control channel before the following operations
can be performed.
n Individual call
D Transmitting
Individual call allows you to make a call to a specific station,
and it provides private communication.
[Individual] key assignment is necessary to transmit the In-
dividual call.
Not available on Non-display types.
q Push [Individual] to enter the Individual ID selection
mode.
INDV
• "INDV" inverts to " ." (for Handhelds)
• The key indicator appears above the key to which [Individual] is
assigned. (for Mobiles)
• A pre-programmed ID name is displayed.
• When the ID name is not programmed, the ID code is displayed.
• Push again to cancel and return to normal operation.
For Handhelds:
INDIVIDUAL1
INDV INDV TGID SET
For Mobiles:
I N D I V I D U A L 1
