5
TACTICAL GROUP FUNCTION
D Cloning the tactical group
<Master (Zone 128) ➔ Sub (Zone 128)> (Continued)
w Turn the sub transceiver power ON.
e Set the master transceiver into the set mode as follows;
For Handheld transceivers:
While pushing [Ω] and [≈] on the master transceiver, ro-
tate [VOL] to turn the power ON.
For Mobile transceivers:
While pushing [P0] and [P4] on the master transceiver,
push [ ] to turn the power ON.
• "DEALER" is displayed.
61
r Input the 6 digit dealer passcode, as specified by your
dealer.
• The 10-keypad* can be used for passcode input.
* 10-key types only
• When using a Simple type transceiver, the keys in the table
shown below can be used for passcode input.
• The transceiver detects numbers in the same block as identical.
Therefore 0 and 5, 1 and 6, etc. are the same.
For Handheld transceivers:
KEY [ ] [I]
Ω
0 1
NUMBER
5 6
For Mobile transceivers:
KEY [P0] [P1]
0 1
NUMBER
5 6
NOTE: When "DEALER" is still displayed after inputting 6
digits, the input code number may be wrong.
In that case, turn the power OFF, and start over.
NOTE: A default passcode is "159357";
Push [I], [Ω], [≈], [III], [Ω], [II] (Handhelds) or [P1], [P0],
[P4], [P3], [P0], [P2] (Mobiles) in sequence.
[II] [III] [ ]
≈
2 3 4
7 8 9
[P2] [P3] [P4]
2 3 4
7 8 9
