Table 2-1 Control - HVAC Field Descriptions (Continued)
Field
HVAC Delay State
HVAC Mode
Fan State
Fan Mode
Internet Managed Thermostat Configuration Guide, Release 1.0
Part No. 600-03001-550, Rev. 1
Description
Displays the HVAC delay state. Delay can be in effect if the interstage delay
is set or if the compressor has been turned off within the last n minutes,
where n is the set time from the Compressor Delay on the Advanced/HVAC
page.
Displays and controls the current mode setting for the HVAC system. The
thermostat can be configured to control the heat system only, cool system
only, automatically change over between heating and cooling systems, or
control neither system.
Off – The thermostat is disabled from controlling either the heating or
cooling system.
Heat – Heating system only.
Cool – Cooling system only.
Auto – Automatic changeover between heating and cooling systems.
Emergency Heat - Forces the activation of an alternative heat source for
heat pumps.
Displays the current state of the HVAC fan.
Off – The operation of the fan is off.
On – The fan is operating.
Displays and controls the current state setting for the HVAC fan.
Auto – Heating or cooling system controls the operation of the fan.
On – User forces the fan to the on state independent of the operation of
the HVAC system.
Scheduled – The operation of the fan adheres to a schedule as defined by
the user on the schedule pages with the schedule profile definition. Note:
When in Scheduled mode, the fan continues to work in Auto mode as
well.
