Beta Draft Confidential
Field
Output Polarity
Include Relay in
OBO

Usage Statistics

The Control - Usage Statistics page displays the usage information.

Figure 2-7 Control - Usage Statistics Page

Use

Table 2-3 Control - Usage Statistics Field Descriptions

Field
Usage Counters
Heating
Fan/Filter
Internet Managed Thermostat Configuration Guide, Release 1.0
Part No. 600-03001-550, Rev. 1
Description
Closed - Normally closed output.
Open - Normally open output.
Displays when OBO is activated if the associated relays using this function
are to be activated as well.
Disabled
Enabled
Table 2-3 to configure the Control - Usage Statistics fields.
Description
Displays thee Heat1 and Heat 2 relay minute activity counter. The Admin
account user can reset this field by checking the Last counter reset box.
Displays the Fan/Filter relay minute activity counter, which is the number
of days, hours, and minutes since the Last counter reset box was checked
and submitted. The Admin account user can reset this field by checking the
Last counter reset box.
Control Page
2-9
