CHAPTER 2: Configuring the Thermostat Using the Web Interface

Thermostat Settings

The Advanced - Thermostat Settings page displays the HVAC system information,
compressor/interstage delay, and maximum cycles per hour, for example.

Figure 2-25 Advanced - Thermostat Settings Page

Use

Table 2-9 Advanced - Thermostat Settings Field Descriptions

Field
General Thermostat Settings
Temperature Scale
Fan on Heat
2-34
Table 2-9 to configure the Thermostat Settings fields.
Internet Managed Thermostat Configuration Guide, Release 1.0
Beta Draft Confidential
Description
Select either the Fahrenheit or Celsius temperature scales.
Fahrenheit (default) – All thermostat temperature readings
and reporting are displayed in the Fahrenheit temperature
°
scale ( F).
Celsius – All thermostat temperature readings and reporting
are displayed in the Celsius temperature scale (
Controls the fan state during heating cycles. In most HVAC
applications the hvac system will wait for the air to warm up
before turning on the fan to circulated the air and the thermostat
does not energize the fan (G) relay. There are some systems
with independent heat sources like electric coils in ducts that rely
on the thermostat to turn on the fan to circulate the air. In this
case you would need to enabel "Fan on Heat."
Enabled – The fan is forced 'on' during heat cycles.
Disabled – The fan is not forced on during heat cycles.
Part No. 600-03001-550, Rev. 1
°
C).
