CHAPTER 2: Configuring the Thermostat Using the Web Interface
Table 2-1 Control - HVAC Field Descriptions (Continued)
Field
Fan Filter Change
Current Schedule
Daily Profile
Event
Heat Setting
Cool Setting
Overrides
Hold/Occupancy
Override
HVAC Settings
HVAC State
2-4
Beta Draft Confidential
Description
Displays a reminder that the time interval between HVAC filter changes has
expired. The air filter(s) should be cleaned or replaced. You should change
the filter and then reset this timer. (See
This field is left blank if no filter change is required.
Required! – The HVAC filters require changing or cleaning.
Displays the current active scheduled Profile.
Displays the current active Event.
Morning
Day
Evening
Night
Displays the current Heat temperature setting as set within the current
schedule.
° ° ° °
40 F(4.5 C) to 110 F(43.5 C)
Displays the current Cool temperature setting as set within the current
schedule.
° ° ° °
40 F(4.5 C) to 110 F(43.5 C)
Displays the current state for both the Heat and Cool Setting. To "Hold" the
current settings indefinitely or for a prescribed period of time as set on the
Override Settings (page 2-35), use the drop-down menu and choose:
Enabled – Hold mode is enabled.
Off (default) – Hold mode is disabled.
Note: When Occupancy Override is visible, it displays the current state of
an active "OBO" button activation.
Displays the current state of the heating or cooling system. If a state change
is made while viewing this page, click Refresh to update the status.
Heat – First stage heat is actively heating.
Heat2 – First stage and second stage heat are actively heating.
Aux Ht – First stage, second stage, and auxiliary heat are actively
heating. (Heat Pump)
Emergency Ht - Emergency heat source is heating.
Cool – First stage A/C is actively cooling.
Cool2 – First stage and second stage A/C are actively cooling.
Off – Neither the heating system or cooling system is active (i.e. on).
Internet Managed Thermostat Configuration Guide, Release 1.0
Alarms Page (page 2-20).)
