Table 2-11 Network - General Field Descriptions - Proliphix IMT550c Configuration Manual

Beta Draft Confidential
Use

Table 2-11 Network - General Field Descriptions

Field
IP Addressing
IP Address Method
IP Address
Subnet Mask
Default Gateway
DNS Server
MAC Address
Web Server
HTTPS Port
Allow HTTP
HTTP Port
Internet Managed Thermostat Configuration Guide, Release 1.0
Part No. 600-03001-550, Rev. 1
Table 2-11 to configure the General fields.
Description
Select the method by which the thermostat receives the unique
Internet Protocol address for the local network. IP addressing
can be either automatically assigned via a local DHCP server or
manually (Static) assigned by the user.
DHCP (default) – IP addressing method is DHCP assigned.
Static – IP address is manually assigned by the user.
Displays the unique Internet Protocol address either assigned
statically or by DHCP. (See IP Address
click Submit after changing this parameter to invoke a software
reset to set the new value.)
A.B.C.D – Four field standard dot notation for IP address
designation.
Displays the IP subnet on which the thermostat IP address is
assigned.
Displays the IP address of the router which acts as a gateway for
the thermostats to communicate to other devices in another
subnet.
Displays the IP address of the Domain Name Server.
Displays a factory assigned value installed in the thermostat
which uniquely identifies the thermostat on the local network for
transmitting and receiving network information.
The system displays the MAC address in the format of
00:19:88:AB:CD:EF for IMT550w and 00:11:49:AB:CD:EF for
IMT550c, where AB:CD:EF is a unique value for each
thermostat.
Enter the IP port number of the Web server within the
thermostat.
xyz – Four digit (max) standard IP port number designation for
HTTP access. The default port number is 443.
Disabled
Enabled
The default is port 80.
Network Page
Method.) (You must
2-39
