- Page 1 Gas-fired boilers GAS 360 S Installation and Service Manual 300005180-001-C...
-
Page 2: Declaration Of Conformity
Royal Decree dated 8th January 2004.: Product type Floor-standing gas boiler GAS 360 S Models 8 - 10 - 12 - 14 sections... -
Page 3: Table Of Contents
Precautions to take in the event of prolonged shutdown (one year or more) ......... .24 04/01/11 - 300005180-001-C GAS 360 S... - Page 4 Spare parts - GAS 360 S ........
-
Page 5: Introduction
France: Performance class III boiler according to ATG B 84 recommendations. 8 sections: Type B11 boiler 10-14 sections: Type B11 boiler 1.3.1 User country Remeha Gas 360 S boilers are delivered preset for operation on group H natural gases. Connection User country Gas type category pressure (mbar) For operation on another gas group, see the chapter "Gas... -
Page 6: Safety Instructions And Recommendations
The appliance should be on Summer or Antrifreeze mode rather than switched off to guarantee the following functions: - Frost protection - Protection against corrosion on domestic hot water tanks fitted with a titanium anode GAS 360 S 04/01/11 - 300005180-001-C... -
Page 7: Technical Description
3 Technical description 3.1 General description Boilers in the GAS 360 S range have the following characteristics: - Cast iron floor-standing gas boiler. - Connecting to a chimney. - Atmospheric burner (2 stages). - Heating body in cast iron with overlapping studs making it possible to obtain extremely high efficiency. -
Page 8: Technical Characteristics
3.2 Technical characteristics Models Gas 360 S/ Stage1 Useful output Stage2 Stage1 39.4 49.1 58.8 58.8 Power input Stage2 68.9 88.4 107.8 127.2 Number of sections Stage1 Kg/h (1) (2) Mass flue gas flow rate Stage2 Kg/h (1) (2) °C... -
Page 9: Main Parts
8 sections: Supplied 10-14 sections: Option (Factory fitted bridge) - Package RD19 10. Factory fitted bridge: Not used 04/01/11 - 300005180-001-C GAS 360 S... -
Page 10: Operating Principle
- If there is a loss of flame in normal operation, the box automatically repeats the start up sequence. - If a flame is present before start-up, the safety control box remains on standby. GAS 360 S 04/01/11 - 300005180-001-C... - Page 11 Flame stabilisation time: Wait 3 seconds Restart waiting time: 1 minutes Safety time: 55 s max tva Alarm time: 15 seconds Waiting time: 0 seconds Auto-control time: 1.5 seconds Box output signals Required input signals 04/01/11 - 300005180-001-C GAS 360 S...
-
Page 12: Installation
General regulations 4.1.2 Other countries Installation and maintenance of the boiler must be carried out by a qualified professional in compliance with prevailing local and national regulations. 4.2 Package list Assembly Instructions GAS 360 S 04/01/11 - 300005180-001-C... -
Page 13: Mounting
= 500 mm ; b = 1400 mm It is forbidden to store inflammable products and materials in the boiler room or close to the boiler, even temporarily. A safety distance of at least 2 metres should be respected. Gas 360 S/ (mm) 1113 1280... -
Page 14: Ventilation
The location of air inlets in relation to the high ventilation openings shall ensure that the air is renewed in the entire volume of the boiler room. Please refer to the prevailing regulations in your country. GAS 360 S 04/01/11 - 300005180-001-C... -
Page 15: Main Dimensions
Heating outlet R 1 1/2 Gas inlet R 1 Heating return R 1 1/2 DTG 230-... S 1113 1280 1447 1007 1007 1007 Ø G R: Tapped connection Rp: Thread 4.3.4 Assembling the appliance Assembly Instructions 04/01/11 - 300005180-001-C GAS 360 S... -
Page 16: Hydraulic Connections
On the other hand, it is important to protect central heating systems against corrosion, scaling and microbiological growth by using a corrosion inhibitor adapted to all types of systems (steel, cast iron radiators, heated floor, PER) GAS 360 S 04/01/11 - 300005180-001-C... -
Page 17: Gas Connection
This pipe must be able to be easily disassembled and must not have a sudden change in diameter. The outlet conduit must be maintained in a good condition, checked and cleaned at least once a year. 04/01/11 - 300005180-001-C GAS 360 S... -
Page 18: Electrical Connections
0.75 mm². For other electrical connections, use the 3 wire cable with a diameter of 0.75 mm². Make the electrical connections: Control panel instructions. Options brochure. 4.8 Skeleton Diagrams Control panel instructions GAS 360 S 04/01/11 - 300005180-001-C... -
Page 19: Start-Up
Top up with more water if necessary. screwdriver. 2. Open the gas valve. 6. Set the On/Off switch to 1. 3. Make the settings on the control panel. 04/01/11 - 300005180-001-C GAS 360 S... -
Page 20: Gas Settings
5.4 Gas settings GAS 360 S boilers are delivered preset for operation on natural These actions must be carried out by a qualified gases of H/E groups. technician. For operation on another group of gases, carry out the following operations. -
Page 21: Setting The Injector Pressure
- Replace the protection caps. When replacing a gas valve: Check that the screw under the protection cap is fully tightened. Carefully set the pressure and progressivity at the opening as described in this chapter. 04/01/11 - 300005180-001-C GAS 360 S... -
Page 22: Setting The Start Up Pressure
Natural gas H 11 mbar Pressure (mbar) Propane 10 mbar Time (s) (1/4 turn) 5.4.5 Attaching the label Affix the label which indicates for which type of gas the boiler is fitted and set. GAS 360 S 04/01/11 - 300005180-001-C... -
Page 23: Pressure Setting And Marking Of Calibrated Injectors
5.4.6 Pressure setting and marking of calibrated injectors Boilers Gas 360 S/ Nozzle pressure (1st stage + 2nd stage) Natural gas H mbar Propane mbar Start-up pressure Natural gas H mbar Propane mbar Nozzle Number of nozzles Natural gas H/E... -
Page 24: Stopping The Boiler
6.2 Precautions to take in the event of prolonged shutdown (one year or more) - Close the gas valve - The boiler and the chimney must be swept carefully. - Close the door of the boiler to prevent the internal circulation of air. GAS 360 S 04/01/11 - 300005180-001-C... -
Page 25: Checking And Maintenance
Do not drain the installation, except in cases of absolute necessity. For example: Several months' absence with the risk of ice in the building. 04/01/11 - 300005180-001-C GAS 360 S... -
Page 26: Checking Burner Safety
The burner goes out. - After checking, re-assemble the smoke duct connecting the heater to the chimney. Wait for around 5 minutes (thermostat cooling time) and press the reset button on the safety control box. GAS 360 S 04/01/11 - 300005180-001-C... -
Page 27: Maintenance
Ignition burner Clean the filter and the ignition burner injector. Remove ionization probe 1 and the earth electrode 2 deposits (for example using sand paper). Carry out a gas tightness check. 04/01/11 - 300005180-001-C GAS 360 S... -
Page 28: Cleaning Of The Heating Body
- Clean the combustion chamber using a vacuum cleaner. 7.2.3 Cleaning painted surfaces - Use a soapy solution and a sponge only. - Rinse with clean water. - Dry with a soft cloth or a chamois leather. GAS 360 S 04/01/11 - 300005180-001-C... -
Page 29: Troubleshooting
Check gas supply Dirty burner Clean the burner Dirty cast iron body (hearth) Insufficient or incorrectly placed Enlarge air supply, smoothen airation holes air supply Gas valve defective Check gas valve and replace if necessary 04/01/11 - 300005180-001-C GAS 360 S... - Page 30 Set the heater thermostat if the heater has SV-matic setting or an ambient requirements thermostat thermostat Injectors too large Flame returns Pressure too weak Check pressure injectors Injectors too small Whistling Pressure too high GAS 360 S 04/01/11 - 300005180-001-C...
-
Page 31: Spare Parts - Gas 360 S
8 Spare parts - GAS 360 S 04/01/11 - 300005180-001-002-B To order a spare part, give the reference number shown on the list 8.1 Boiler body + Draught diverter 04/01/11 - 300005180-001-C GAS 360 S... -
Page 32: Gas Line
8.2 Gas line 8.2.1 8-10-12 sections GAS 360 S 04/01/11 - 300005180-001-C... -
Page 33: Sections
8.2.2 14 sections 04/01/11 - 300005180-001-C GAS 360 S... -
Page 34: Control Panel K
8.3 Control panel K 8.4 Control panel K + Components GAS 360 S 04/01/11 - 300005180-001-C... -
Page 35: Metal Casing For Control Panel K
8.5 Metal casing for control panel K 8.6 Boiler body insulation 04/01/11 - 300005180-001-C GAS 360 S... -
Page 36: Casing
9755-0722 Rear insulation - 12 sections 8377-5508 Assembly rod M8 - LG1000 9755-0724 Rear insulation - 14 sections 8377-5509 Assembly rod M8 - LG1080 9754-9668 Water flow pipe 8377-5510 Assembly rod M8 - LG1170 GAS 360 S 04/01/11 - 300005180-001-C... - Page 37 Burner support - 10 sections 8377-8190 Flame non-return plate - 12 sections 8502-5575 Burner support - 12 sections 8377-8192 Flame non-return plate - 14 sections 8502-5577 Burner support - 14 sections 8800-8961 Glue 1000 (100 ml can) 04/01/11 - 300005180-001-C GAS 360 S...
- Page 38 Complete casing - 8 sections 200003821 Complete casing - 10 sections 200003822 Complete casing - 12 sections 200003823 Complete casing - 14 sections 8502-8839 Front plate - 8 sections 8502-8841 Front plate - 10 sections GAS 360 S 04/01/11 - 300005180-001-C...
- Page 39 04/01/11 - 300005180-001-C GAS 360 S...
- Page 40 © Copyright All technical and technological information contained in these technical instructions, as well as any drawings and technical descriptions supplied, remain our property and shall not be multiplied without our prior consent in writing. Subject to alterations. 04/01/11...
