Lay the assembled trolley on its side. Lay the body (B1) on its back and slide into position between

the trolley legs. Warning: Care must be taken to ensure lid does not fall open unexpectedly.

With the barbecue laid on the ground, insert a M6x145 bolt (D6) through the short leg,

through a spacer (D7), and secure the bolt into the sidewall of the body. repeat the process

for all the legs until the body is completely fixed to the trolley.

When positioning the body of the barbecue, ensure the control panel is on

NOTE:

the same side as the legs with Velcro fastenings
