Sapphire 2 Burner, 3 Burner, 6 Burner Stainless Gas Barbecues
Photographs are not to scale.
Specifications subject to change
without prior notice.
•
For outdoor use only.
•
Read instructions before using the appliance. Failure to follow instructions
could result in death, serious bodily injury, and/or property loss.
•
Warning: accessible parts may be very hot. Keep young children away.
•
Do not move the appliance during use.
•
Turn off the gas supply at the gas bottle after use.
•
Any modification of the appliance, misuse, or failure to follow the instructions
may be dangerous and will invalidate your warranty. This does not affect your
statutory rights.
WARNING
•
Retain these instructions for future reference.
•
Leak test your barbecue annually. Check the hose connections are tight and
leak test each time you reconnect the gas bottle.
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
Elite Series Barbecues
Assembly and Operating Instructions for Outback®
1.
2.
FOR YOUR SAFETY
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
0359
Advertisement
Table of Contents
Related Manuals for Outback Sapphire 2 Burner
Summary of Contents for Outback Sapphire 2 Burner
-
Page 1: For Your Safety
Elite Series Barbecues Assembly and Operating Instructions for Outback® Sapphire 2 Burner, 3 Burner, 6 Burner Stainless Gas Barbecues Photographs are not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss. -
Page 2: Parts List
Parts List Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram’. Outback® Sapphire Outback® Sapphire Outback® Sapphire CODE PART 2 Burner 3 Burner 6 Burner Hood Handle... -
Page 3: Parts Diagrams
Parts Diagrams Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram.’... - Page 4 Hardware Reference Diagram Specifications subject to change without prior notice. D2 (screw) D3(washer)
- Page 5 Assembly IMPORTANT! • Tools Required: Medium size flat blade or Phillips/Crosspoint screwdriver, adjustable spanner or metric spanner set • The assembly of this barbecue requires 2 people. • Carefully unpack the parts from the box and remove all internal packaging before commencing assembly. All loose items including the grills, griddle, flame tamers and warming basket must be removed from the body.
- Page 6 Attach the Bottom Slat Assembly (C12) to the Base Tray (C13) using the Screws (D2). Attach the leg assembly to the Base Tray (C13) using the Screws (D2).
- Page 7 Threaded Insert Attach the Front Left Leg (C8) and Rear Left Leg (C9) to the Gas Bottle Holder (C14). Note: Threaded inserts must be facing in the direction shown! Align the Gas Bottle Holder (C14) with the Slat Assembly (C12).
- Page 8 Attach the Gas Bottle Holder (C14) to the Bottom Slat Assembly (C12) using the Screws (D2) Attach the Gas Bottle Holder (C14) to the Bottom Slat Assembly (C12) using the Screws and Washers (D3). (D2) and Washers (D3). Insert the axle (C19) through the clamping brackets on the gas bottle holder (C14) and tighten the clamp screws.
- Page 9 Place the Wheels (C17) onto the Axle (C19) and secure with Locknuts (C18). Carefully turn the completed trolley over, right side up.
- Page 10 CAUTION! Care must be taken to ensure hood does not fall open unexpectedly or that the hood surface is damaged when set on the ground. Carefully turn the Barbecue Body (B1) upside down and remove the Drip Tray (B5). Attach the R/H Side Shelf (C6) to the Barbecue Body (B1) using the Screws (D2).
- Page 11 Attach the Rear Left Endcap (C4) to the Body (B1) using the Screws (D2). CAUTION! Care must be taken to ensure hood does not fall open unexpectedly. Carefully turn the Barbecue Body (B1) over right-side-up.
- Page 12 Carefully lay the Barbecue Body (B1) onto the tops of the legs. The tops of the legs should slot into the endcaps. When done correctly, the barbecue should be able to stand on its own weight. WARNING: DO NOT RELEASE THE BARBECUE BODY WHILE THE BARBECUE HAS NOT BEEN PROPERLY SEATED.
- Page 13 Attach the Side Shelf Shield (C2) to the endcaps using the Countersunk Screws (D1). Attach the Side Shelf Hook (C22) to the L/H Side Shelf (C1) using the Screws (D5), Hook the side shelf to the endcaps.
- Page 14 Lay the Utensil Trays (C5) into their positions on either side of the barbecue body. Place the Wheel Hubcaps (C16) onto the sides of the Wheels (C17)
- Page 15 Slide the loops of the Gas Bottle Strap (C21) onto the Retaining Rod (C20). Secure the Rod (C20) to the trolley legs using the Screws (D2). Ensure the strap is threaded through the buckle correctly. It must hold the gas bottle firmly in place onto the barbecue.
- Page 16 Place the Foil Liner (B7) into the Drip Pan (B6) and slide into place. Remove the plastic wrap from the Flame Tamer (B8) and lay them carefully into the body ensuring that they lie level within the body. Lay the Grills (B9) and Griddle (B10) into place. 2 Burner Configuration: Left half - Grill, Flame Tamer;...
- Page 17 Connect the gas hose (B11) to the BBQ. Ensure the mating faces of the connection are clean and not damaged. Do not use any sealing tape, paste, or liquid on the joint. The nut must be tightened with the use of a spanner. Do not use force which may damage the assembly. Assembly is now complete.
-
Page 18: Essential Information
ESSENTIAL INFORMATION Please read instructions before using your barbecue. BEFORE YOU USE YOUR BARBECUE (also see installation) • Perform a leak test. This is the only safe and sure way to detect any gas leaking from joints and connections of the barbecue after assembly. Follow the leak test instructions on page 20. Check that the gas hose is free of any tension, twisting, cuts, or cracks. -
Page 19: Gas, Regulator And Hose
• If you intend to leave your barbecue outside make sure it is protected from the elements by a heavy duty cover, these are available from most Outback® stockists. • Even when your barbecue is covered for its protection, it must be inspected on a regular basis as damp or condensation can form which may result in damage to the barbecue. -
Page 20: Installation
Repeat test • If bubbles form again do not use the barbecue and contact your local Outback dealer for assistance or call Outback customer services on (01622) 671771. Customer services are available during normal office hours, Monday to Friday, 9am to 5pm. -
Page 21: Maintenance
Confirm that each burner is lit before turning on the next burner. • If the right hand burner fails to light, turn off the gas and contact your local Outback dealer or our customer services department on (01622) 671771 for assistance. - Page 22 Burner Removal To remove the burners (see photos): 1. Remove the burner retaining clip from underneath the burner support. 2. Remove the cross channel lighter bar from the burner. 3. Lift the back of the burner upwards and pull away from the opening and the gas valve at the front of the barbecue.
- Page 23 Cleaning Material Where used Cleaning Method Recommended Stainless Centre hood panel Clean using hot soapy water or with the use of a suitable Steel cleaning product following the manufacturers instructions. Porcelain Grills Enamel is a thin, glass based coating fused onto metal and enamel Griddles as such needs to be treated with care.
- Page 24 Troubleshooting Problem Possible Cause Solution Burners will not light LP gas bottle is empty Replace with full gas bottle using the ignition system Faulty regulator Have regulator checked or replace Obstructions in burners Clean burners Obstructions in gas jets Clean jets and gas hose or gas hose Electrode wire is loose or Reconnect wire...
-
Page 25: Technical Specifications
Technical Specifications Injector Gas / Model Name Heat Input Burners Approval Size Pressure Outback® 0359 7.87kW 1.04 Sapphire 2 359AS128 Burner Butane/ 28-30mbar Outback® 0359 11.8kW 1.04 Sapphire 3 359AS128 Burner Propane/ 37mbar Outback® 0359 15.75kW 0.81 Sapphire 6 359AS128... - Page 26 OUTBACK UK LTD LIMITED 10 YEAR WARRANTY OUTBACK barbecues are warranted to the original purchaser against defects in materials and workmanship. Porcelain coated barbecue bodies, porcelain coated roasting hoods and stainless steel roasting hoods are warranted for a period of ten (10) years from the date of purchase.
