inside of the cover if used. Mould can grow
under these conditions and should be
cleaned and treated if required. Any rust
that is found that does not come into
contact with the food should be treated with
a rust inhibitor and painted with barbecue
paint or a heat resistant paint. Wooden
parts may also need to be cleaned and re
oiled. Chrome plated warming racks etc.
should be coated with cooking oil. Wrap the
burners in aluminium foil to help prevent
insects or other debris from obstructing the
burners.
The gas bottle must be
disconnected from the barbecue and stored
in a well ventilated area at least 1 metre
away from any fixed ignition source. Do not
store inside residential accommodation.
Never store cylinders below ground level
(e.g. cellars). Do not let children tamper
with bottles.
J. Technical Specifications
Outback®
Spectrum
2 Burner
Outback®
Spectrum
3 Burner
Countries of Use:
I
3+ (28-30/37)
I
3B/P(30)
always be
Specifications are subject to change without prior notice
16
CE Heat
Burners
Approval Input
0359
8.8kW
359AS128
0359
13.2kW
359AS128
BE, CY, CZ, EE, FR, GR, IE, IT, LV, LT, LU, PT, SK, ES,
CH, GB, RO
BG, CY, CZ, DK, EE, FI, GR, HR, LV, LT, LU, MT, NL, NO,
SK, SI, SE, TR, IS
Injector Gas /
Size Pressure
2
Butane/28
-30mbar
1.1
Propane/
37mbar
3
.
