2.3.3 CompactFlash™ Voltage Jumper (JP3)
The jumper is to select the voltage for CompactFlash
Description
Compact Flash
Voltage
Selection
JUMPERS AND CONNECTORS
SBC84833 Series All-In-One Capa Board User's Manual
Function
Jumper Setting
3.3V
(Default)
5V
™
interface.
