M Series User Guide
FIGURE 28: Select the desired layout in the combo-box.
6.3.2

Real Device

Working on the real device remotely is also possible. In this case
all changes made to a device are immediately audible. In order to
work on a real device:
1. Connect the device and discover the connected units. (see
Section 6.2.2 on page 16)
2. Drag the remote device into the workspace onto the virtual
device.
FIGURE 29: Drop the discovered device on the virtual device; when
the arrow appears, release the left mouse button.
3. If the internal device setup is different you'll be prompted to
select the realignment direction
FIGURE 30: Realign window, asking for synchronization.
By selecting yes the device setup is transmitted from the virtual
device to the real device. By selecting no the device setup is
transmitted from the real device to the virtual one.
WARNING: by answering "yes" to the realignment question,
the M Series device loses data on the selected preset slot.
4. It is now possible to operate on the device. Refer to Section
6.5 on page 20) for all possible operations.
18
▶
WARNING: remember that turning off or disconnecting the
power plug without saving changes on any internal memory slot
leads to data loss. Before turning off, save the data on any internal
slot or export to a .pam file.

6.4 File Operations

There are several import/export possibilities from/to files on a
M Series unit. This section contains an explanation of all possible
cases.
WARNING: due to the internal structure of the device, some
of these file operations can cause a temporary interruption of
audio.
6.4.1

Binary Preset File .preset

Handling of the internal binary preset of an M Series DSP module
is possible in the preset tab of the device.
FIGURE 31: MxxD have only one DSP module.
FIGURE 32: MxxQ have two DSP modules. It is therefore necessary
to change both slots.
EXPORT, export the actual preset slot to a .preset file.
▶
WARNING: if the actual playing preset wasn't saved before
export, the exported binary will be the last stored binary and not
