M Series User Guide
the current playing preset.
IMPORT, save a .preset file on the selected slot and recall
▶
that slot.
WARNING: this leads to a couple of seconds interruption of
the audio stream.
WARNING: the data contained in a .preset file irreversibly
modifies a preset slot and its internal layout.
6.4.2

Input/Output Curves .icp, .ocp

From the input or output tab of an M Series device, import/export
of the current equalization curve is a straightforward procedure.
FIGURE 33: The output eq: there are 4 possible choices to handle the
curve.
WARNING: all changes will be lost if the preset is NOT stored
on board before unplugging the unit from the mains.
6.4.3

Channel Preset .chp

Import/export of the current playing processing from/to a file is
possible by starting from the device's layout.
FIGURE 34: All possible channel operations are available by right
clicking on the respective channel.
Imported and/or exported data is:
Input eq
▶
19
▶
Output eq
▶
Limiters
▶
Damping factor control
▶
WARNING: all changes will be lost if the preset is NOT stored
on board before unplugging the unit from the mains.
NOTE: importing channel preset files doesn't modify the internal
structure of a device. For example, a channel exported from a 1
in / 2 out configuration doesn't affect the internal structure when
imported in 2 in /2 out processing layout.
NOTE: in the 1 in / 2 out configuration, the input eq is exported
(or applied) to both input eq's. For example, exporting 1 in /2 out
configurations exports the unique input eq to both channels.
6.4.4

Device preset file .pam

The preset file allows to import/export entire dumps of the
device. An exported .pam file allows to completely replicate the
DSP process on another device. In order to import/export a .pam
file:
Select the device (a blue rectangle will appear)
▶
Right click on the selected device
▶
Click on import/export
▶
When importing a .pam file you'll be prompted for a decision on
the realignment policy to adopt.
By selecting yes, the device setup is transmitted from the virtual
device to the real device. By selecting no, the device setup is
transmitted from the real device to the virtual device.
WARNING: importing a .pam file leads to a short interruption
of the audio stream.
WARNING: importing a .pam file overwrites the current preset
slot on the device. Any previous data on the slot will be erased.
FIGURE 35: The .pam import/export operation from the workspace.
Note the blue rectangle on the selected device.
6.4.5

System File .paw

Saving or opening a system file permits the storage of the entire
