IDE and SATA Configuration
SATA#1 Configuration
IDE Detect Timeout (sec)
007-5653-001
When this submenu is selected, the AMI BIOS automatically detects the presence of the IDE
devices and displays the following items:
Configure SATA#1 as
Selects the drive type for SATA#1. The options:
•
IDE
•
RAID (Intel) - Enables configuration of the Intel SATA RAID settings.
•
RAID (Adaptec) - Enables configuration of the Adaptec SATA RAID settings.
•
AHCI - Enable the SATA Advanced Host Interface. This feature is for advanced
programmers only.
Use this feature to set the time-out value for the BIOS to detect the ATA, ATAPI devices installed
in the system. The options are 0 (sec), 5, 10, 15, 20, 25, 30, and 35.
Advanced Setup Configurations
61
