 Overview
The QDSP-5001 Series is a fanless Box PC ideal for space critical applications. This
embedded hardware platform features Intel
®
Intel HM76 Express chipset, and DDR3 1333/1600 SO-DIMM. It comes with 2.5"
SSD, mSATA, 2x Mini-PCIe slots, HDMI, 2x DP, 2x USB2.0, 4x USB3.0, 2x COM,
and Audio. The QDSP-5001 provides triple-independent display and dual storage,
high reliability rugged case not only for great protection from EMI, cold and heat, but
also integrated with passive cooling design for quiet fanless operation such as Digital
Signage.
Checklist
QDSP-5001 series

Power Adapter

Power Cord

Driver CD

Quick installation Guide

Optional VESA-mount and Wall-Mount

Optional wireless LAN / 3G

Features
®
Intel Celeron Dual Core / Core i Processor

DDR3 1333/1600 MHz memory support up to 16 GB

1x HDMI, 2x DP, 1x S/PDIF Output and Clear CMOS

2x USB2.0, 4x USB3.0, 2x COM, 2x GbE LAN and Audio

1x mSATA, 2x Mini-PCIe slots

Triple-independent display /Dual storage

TPM, iAMT supported

Optional VESA-mount and Wall-Mount

