PANEL DESCRIPTION

■ Front, top and side panels

D KEYPAD (Continued)
[3] • [T.SCAN](3)
➥ Numeric input and DTMF code: '3'
➥ After pushing [FUNC](M), starts a tone scan.
(p. 26)
[4] • [T/A](4)
➥ Numeric input and DTMF code: '4'
➥ After pushing [FUNC](M), turns the Talk Around
function ON or OFF. (p. 19)
[5] • [SCAN](5)
➥ Numeric input and DTMF code: '5'
➥ After pushing [FUNC](M), starts a scan. (p. 19)
[6] • [SKIP](6)
➥ Numeric input and DTMF code: '6'
➥ After pushing [FUNC](M), sets or cancels the skip
setting. (p. 22)
[7] • [PRIO](7)
➥ Numeric input and DTMF code: '7'
➥ After pushing [FUNC](M), starts a priority watch.
(p. 23)
[8] • [SET](8)
➥ Numeric input and DTMF code: '8'
➥ After pushing [FUNC](M), enters the Set mode.
(p. 30)
5
[9] • [H/M/L](9)
➥ Numeric input and DTMF code: '9'
➥ After pushing [FUNC](M), selects the output
power between high, mid and low. (p. 16)
[0] • [DTMF-M](0)
➥ Numeric input and DTMF code: '0'
➥ After pushing [FUNC](M), enters the DTMF mem-
ory mode. (p. 27)
[M] • [FUNC](M)
➥ DTMF code: 'M (indication: E)'
➥ Push to access the second function of other
keys.
[# ENT] • [MN.W](# ENT)
➥ DTMF code: '# (indication: F)'
➥ After entering a channel number (0-9), push to set
the channel. (p. 15)
➥ Push to exit the Set mode or Initial Set mode.
(pp. 30, 34)
➥ After pushing [FUNC](M), hold down for 1 second
to enter the channel name programming mode.
(p. 18)
