■ Battery chargers

D Using the BC-191 to rapid charge the BP-264
The BC-191 rapidly charges only the BP-264 Ni-MH battery
pack. Never use it to charge any other battery pack.
Charging time: Approximately 2 hours
The following additional item is required:
• An AC adapter (not supplied with some versions) or the OPC-515L
or CP-23L DC power cable.
Battery pack
AC adapter
(A different type, or no AC
adapter is supplied with
some versions.)
The optional OPC-515L (for DC
power source) or CP-23L (for 12 V
cigarette lighter socket) can be
used instead of the AC adapter.
Transceiver
Turn OFF the power
Screws*
(Self tapping screw:
3.5 × at least 30 mm)
*Purchase separately.
Using screws is
recommended to
secure the charger.
Charge indicator
• Lights orange : While charging
• Lights green : Charging is completed.
BATTERY CHARGING
D Using the BC-192 to regular charge the BP-264
The BC-192 regularly charges only the BP-264 Ni-MH bat-
tery pack. Never use it to charge any other battery pack.
Charging time (with the 147S): Approximately 16 hours
The following additional item is required:
• An AC adapter (not supplied with some versions) or the OPC-515L
DC power cable.
Battery pack
AC adapter
(A different type, or no AC
adapter is supplied with
some versions.)
The optional OPC-515L
(for DC power source)
can be used instead of
the AC adapter.
Charging time period differs
depending on the input voltage.
12 V : Approx. 36 hours
13.8 V : Approx. 21 hours
16 V : Approx. 16 hours
3
1
2
3
4
5
6
Transceiver
7
8
9
10
11
12
Turn OFF the power
Screws*
13
(Self tapping screw:
3.5 × at least 30 mm)
14
*Purchase separately.
Using screws is 15
recommended to
secure the charger. 16
Charge indicator
17
• Lights green while charging.
NOTE: 18
The charge indicator will not
go out even after a battery 19
pack is fully charged.
