Icom IC-G80 Instruction Manual page 17

D Using the BC-197 to rapid charge the BP-264 or BP-265
The BC-197 rapidly charges up to six battery packs.
Charging time for BP-264: Approximately 2 hours
Charging time for BP-265: Approximately 2.5 hours
The following additional item is required:
• An AC adapter (not supplied with some versions) or the DC
power cable (OPC-656)
There are two types of BC-197 chargers for the IC-G80; one
is for Ni-MH batteries, and the other is for Li-Ion batteries.
Before you purchase a BC-197, check the type of battery you
are using, and then be sure to choose the suitable charger.
BC-197 Charger Type
With AD-120* charger adapters
With AD-121* charger adapters
* The type of the charger adapter, AD-120 or AD-121 is printed on
the inside bottom of the charger adapter, and the type of battery it
holds is printed on the top right corner of the adapter.
Chargeable Battery
BP-264 Ni-MH battery
BP-265 Li-Ion battery
BATTERY CHARGING
Battery
pack
Charger adapters* are
1
installed in each slot.
DC power cable
(Connect to a DC power supply;
12 to 16 V/at least 7 A)
*
1 The shape of charger adapter depends on the version of the BC-197.
*
2 Red line : + Black line : _
About the OPC-656
Transceiver
Turn OFF the power
AC adapter
(An AC adapter is
not supplied with
some versions.)
(OPC-656* )
