PANEL DESCRIPTION

Front, top and side panels (for the Portable type transceiver)

[Selector]
Antenna
Connector
[Emer]
[F1]
[PTT]
[OK]
[F2]
[F3]
[Up]/[Down]
[Right]/[Left]
Micro USB
Connector
The illustration is of the Ten-key types.

D About the transceiver types

There are 2 types of transceivers.
IC-F7010S, IC-F7020S, IC-F7040S: Simple key types
IC-F7010T, IC-F7020T, IC-F7040T: Ten-key types
[VOL]

D About the Status indicator

AB Switch
• Lights white, then blinks red, yellow, and green when
Status
turning ON the transceiver.
indicator
• Lights red while transmitting.
• Lights green while receiving a signal, or when the
Microphone
squelch is open.
Function
• Blinks magenta when the battery is exhausted.
Display
Multi-

D About the Multi-connector

connector
Connects to an optional speaker microphone or
[P1]
headset.
[P2]
CAUTION: DO NOT use the transceiver without the
[Back]
connector cover or optional device attached.
The transceiver meets IP68 requirements for dust-
tight and waterproof protection only when the
Ten-Key
connector cover or the optional device is attached.
Pad
microSD

D About the Software key functions

Card Slot
NOTE: Dealers can assign the Software key
Speaker
functions to the keys, keypads, and the AB Switch.
LSee page 2-11 for details.
