Ku-Band Solid-State Power Amplifier
Specifications
Parameters
Input
Level
Impedance
Noise Figure
VSWR
Connector
Output
Frequency
Power
Mute
VSWR
Connector
Gain
Linear
Adjust
Fill Band
Per 40 MHz
0 to +50°C (32 to 122°F)
Third Order Intermodulation
Intercept
Products
AM to PM Conversion
Output
Group Delay (per 40 MHz)
Linear
Parabolic
Ripple
Table A-1. KPS-020IN Specifications
Specifications
-10dBm Typical
50Ω
10 dB Typical, 15 dB max at max gain
1.25: 1 maximum
SMA Female
14.0 to 14.5 GHz
42.5 dBm minimum at 1 dB Compression
60 dB
1.25:1 maximum
WR75G Waveguide
50 dB minimum, 53 dB Typical
20 dB in 0.25 dB steps
± 0.75 dB
± -0.25 dB
± 0.75dB
+56.5 dBm minimum, 59.0 Typical
-25 dBc max, -30 dBc typical
at 3 dB total backoff from rated P1dB
(two tones, ∆f+MHz)
2.0 degrees typical
3.0 max at 42.5 dBm
± 0.03 ns/MHz
± 0.0025 ns/MHz
1.0 ns Peak-to-Peak
