4.1
General
The front panel of the KPA has a keypad for the operator input commands, an LCD
Display, LED status indicators, and connector test sample ports to monitor the RF input
and output signals.
4.1.1
Front Panel
The front panel contains a User Interface keypad which is used by a local operator to
input commands to the KPA. The keypad is used to select the configuration for operating
and monitoring the status of the KPA.
In conjunction with the front panel two line, 24-character, LCD display, the keypad
allows the operator to select one of five configurations. The configuration functions are:
Revision 0
Chapter 4. Operation
•
Configuration Menu
•
Monitor Status Menu
•
Currents Faults Menu
•
Stored Faults Menu
•
Utility Functions Menu
4-1
