Ku-Band Solid-State Power Amplifier
Operation
4.2.1.4

SELECT: STORED FAULTS MENU

The KPA displays a total of 100 faults with a date/time stamped and stored in memory as
they occur. The stored faults remain in memory until a Clear commanad is entered.
SELECT: STORED FAULTS MENU: TOTAL STORED FAULTS
Displays the total number of faults stored. The most recent fault stored is displayed on the
LCD display.
SELECT: STORED FAULTS MENU: CLEAR ALL STORED
FAULTS
Displays the total number of faults stored. The most recent fault stored is displayed on the
LCD display.
SELECT: STORED FAULTS MENU: DISPLAY STORED FAULTS
The local operator can sequence through the stored faults starting with the most recent
fault. The Fault number, time, description, and date are displayed on the LCD display.
TOTAL-FAULTS-STORED: 100
LAST-19:20:05---02/15/95
----CLEAR-ALL-STORED----
------FAULTS?-NO--------
ST-FAULT-XX-----19:20:05
OK-FINE-LOCK----02/15/95
