Chapter 3: Uefi Setup Utility

3.3.10 USB Configuration

Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
USB 2.0 Controller
[Enabled]
USB 2.0 Controller
[Enabled]
Legacy USB Support
[Enabled]
Legacy USB 3.0 Support
[Enabled]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
USB 2.0 Controller
Use this item to enable or disable the use of USB 2.0 controller.
USB 3.0 Controller
Use this item to enable or disable the use of USB 3.0 controller.
Copyright © 2011 NEXCOM International Co., Ltd. All Rights Reserved.
Legacy USB Support
Use this option to select legacy support for USB devices. There are four
configuration options: [Enabled], [Auto], [Disabled] and [UEFI Setup Only].
The default value is [Enabled]. Please refer to below descriptions for the
details of these four options:
[Enabled] - Enables support for legacy USB.
To enable or disable USB 2.0
Controller.
[Auto] - Enables legacy support if USB devices are connected.
[Disabled] - USB devices are not allowed to use under legacy OS and UEFI
setup when [Disabled] is selected. If you have USB compatibility issues, it is
recommended to select [Disabled] to enter OS.
[UEFI Setup Only] - USB devices are allowed to use only under UEFI setup
and Windows / Linux OS.
→←: Select Screen
Legacy USB 3.0 Support
↑↓: Select Item
Enter: Select
+/-: Change Opt.
Use this option to enable or disable legacy support for USB 3.0 devices.
F1: General Help
F7: Discard Changes
The default value is [Enabled].
F9: Load UEFI Defaults
F10: Save & Exit
F12: Print Screen
ESC: Exit
37
NEX 883 User Manual
