Chapter 3: Uefi Setup Utility
3.1.2 Navigation Keys
Please check the following table for the function description of each
navigation key.
Navigation Key(s)
/ Moves cursor left or right to select Screens
/ Moves cursor up or down to select items
+ / - To change option for the selected items
<Enter> To bring up the selected screen
<F1> To display the General Help Screen
<F7> Discard changes
<F9> To load optimal default values for all the settings
<F10> To save changes and exit the UEFI SETUP UTILITY
<F12> Print screen
<ESC> To jump to the Exit Screen or exit the current screen
Copyright © 2011 NEXCOM International Co., Ltd. All Rights Reserved.
Function Description

3.2 Main Screen

When you enter the UEFI Setup Utility, the Main screen will appear and
display the system overview.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced H/W Monitor
UEFI Version : IMB-370-L L0.03
Processor Type : Intel(R) Core(TM) i7-3770 CPU @ 3.40GHz
Processor Speed : 3400MHZ
Microcode Update : 306A8/10
: 8192KB
Cache Size
Total Memory : 1024 MB with 64MB Shared Memory and
2MB Single-Channel Memory Mode
: None
DDR3_A1
DDR3_A2 : None
DDR3_B1 : None
DDR3_B2 : 1024 MB (DDR3-1333)
System Date [Tue 10/30/2012]
System Time [17:24:08]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
26
Boot Security Exit
Set the Date. Use Tab to switch
between Data elements.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F7: Discard Changes
F9: Load UEFI Defaults
F10: Save & Exit
F12: Print Screen
ESC: Exit
NEX 883 User Manual
