Chapter 1: Introduction
Controller
VRAM
DSub
LVDS
Graphics
HDMI
DVI
Display Port
Multi Display
Interface
Ethernet Controller
Controller
Max Data
SATA
Transfer Rate
VGA
HDMI
DVI
Display Port
Ethernet
Rear I/O
USB
Audio
Serial
PS/ 2
Copyright © 2011 NEXCOM International Co., Ltd. All Rights Reserved.
Intel HD Graphics (By CPU)
®
Shared Memory
Through DVI-I, Supports max resolution
2048 x 1536
Dual Channel 24bits, Support max
resolution 1920 x 1200 (Shared with
DisplayPort)
Support HDMI 1.4a, max resolution 1920
x1200
Support max resolution 1920 x1200
Support max resolution 2560 x1600
Yes
10/100/1000 Mbps
GbE LAN1:Intel ® 82579LM/ V, LAN2:
Intel 82583V
®
RJ-45 x 2 w/ LED
SATA2 X2 (3.0Gb/S), SATA3 X2
(6.0Gb/S), Support RAID0/1/5
0 (Can transfer from DVI-I)
1
1 (DVI-I)
1
2
6 (USB 2.0 x 4, USB 3.0 x 2)
3 (Mic-In, Line-Out, Line-In)
2 (RS-232/ 422/ 485)
1 (Combo)
USB
LVDS/ Inverter
VGA
Serial
SATA
m-SATA
Internal Con-
nector
Mini-PCIE
Parallel
IrDA
GPIO
SATA PWR
Output Con
Speaker Header
Watchdog
Output
Timer
Interval
Input PWR
Power Require-
ments
Power On
Environment Temperature
2
6 (USB 2.0 x 4, USB 3.0 x 2)
1/ 1
0
4 (RS-232)
4 (SATA2 x 2 (3.0Gb/ S), SATA3 x 2
(6.0Gb/ S), Support RAID0/ 1/ 5)
1
1
1
0
4 x GPI + 4 x GPO
2
1
Output from super I/O to drag
RESETCON#
256 Segments, 0,1,2...255 Sec/ Min
ATX PWR
AT/ ATX Supported
-AT : Directly PWR on as power input
ready
-ATX : Press button to PWR on after
power input ready
0ºC ~ 60ºC
