North Bridge Configuration - Nexcom NEX 883 User Manual

Chapter 3: Uefi Setup Utility

3.3.2 North Bridge Configuration

Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset PCIPnP
VT-d Capability Supported
DRAM Frequency [Auto]
Primary Graphics Adaper [PCI Express]
VT-d [Disabled]
PCIE1 Link Speed [Atuo]
Share Memory [Atuo]
IGPU Multi-Monitor [Disabled]
RenderStandby [Enabled]
Deep Render Standby [Enabled]
Actlve LVDS [Enabled]
Panel Type Selection [1600x900/18-bit/2-...]
Primary IGFX Boot Display [VBIOS Default]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
DRAM Frequency
If [Auto] is selected, the motherboard will detect the memory module(s)
inserted and assign the appropriate frequency automatically.
Primary Graphics Adapter
This allows you to select [Onboard], [PCI] or [PCI Express] as the boot
graphic adapter priority. The default value is [PCI Express].
VT-d
Use this item to enable/ disable Intel
Directed I/O.
Copyright © 2011 NEXCOM International Co., Ltd. All Rights Reserved.
Security Exit
Select DRAM Frecuency.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F7: Discard Changes
F9: Load UEFI Defaults
F10: Save & Exit
F12: Print Screen
ESC: Exit
Virtualization Technology for
®
PCIE1 Link Speed
This allows you to select PCIE 1 Link Speed. The default value is [Auto].
Share Memory
This allows you to set onboard VGA share memory feature. The default
value is [Auto].
IGPU Multi-Monitor
This allows you to enable or disable IGPU Multi-Monitor. The default value
is [Disabled]. If you wish to install a PCI Express card under Windows
/ Vista OS, please disable this option.
TM
Render Standby
Use this to enable or disable Render Standby by Internal Graphics Device.
The default value is [Enabled].
Deep Render Standby
This allows you to enable or disable Deep Render Standby. The default
value is [Enabled].
Active LVDS
Use this to enable or disable the LVDS. The default value is [Enabled].
Panel Type Selection
Use this to select panel type.
Primary IGFX Boot Display
Select the Video Device which will be activated during POST. This has no
effect if external graphics present. Secondary boot display selection will
appear based on your selection. VGA modes will be supported only on
primary display. Configuration options: [VBIOS Default], [CRT], [DVI],
[HDMI] and [LVDS]. The default value is [VBIOS Default].
30
® XP
NEX 883 User Manual
