3.3.3 South Bridge Configuration

Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main
Advanced Chipset
Onboard HD Audio [Auto]
Front Pane1 [Atuo]
Onboard HDMI HD Audio [Enabled]
Onboard LAN 1 [Enabled]
Onboard LAN 2 [Enabled]
Deep Sleep [Disabled]
Restore on AC/Power Loss [Power Off]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Onboard HD Audio
Select [Auto], [Enabled] or [Disabled] for the onboard HD Audio feature. If
you select [Auto], the onboard HD Audio will be disabled when PCI Sound
Card is plugged.
Front Panel
Select [Auto] or [Disabled] for the onboard HD Audio Front Panel.
Onboard HDMI HD Audio
This allows you to enable or disable the Onboard HDMI HD Audio feature.
Copyright © 2011 NEXCOM International Co., Ltd. All Rights Reserved.
Exit
PCIPnP Security
Atuo/Enabled/Disabled
Onboard HD Audio
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F7: Discard Changes
F9: Load UEFI Defaults
F10: Save & Exit
F12: Print Screen
ESC: Exit
Onboard LAN 1
This allows you to enable or disable the Onboard LAN 1 feature.
Onboard LAN 2
This allows you to enable or disable the Onboard LAN 2 feature.
Deep Sleep
.
Mobile platforms support Deep S4/S5 in DC only and desktop platforms
support Deep S4/S5 in AC only. The default value is [Disabled].
Restore on AC/Power Loss
This allows you to set the power state after an unexpected AC/power loss.
If [Power Off] is selected, the AC/power remains off when the power
recovers. If [Power On] is selected, the AC/power resumes and the
system starts to boot up when the power recovers.
