Chapter 3: Uefi Setup Utility

3.3.9 ACPI Configuration

Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Suspend to RAM [Auto]
Check Ready Bit [Enabled]
ACPI HPET Table [Enabled]
PS/2 Keyboard Power on [Disabled]
PCI Devices Power on [Disabled]
Ring-In Power on [Disabled]
RTC Alarm Power on [By OS]
USB Keyboard/Remote Power on [Disabled]
USB Mouse Power on [Disabled]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Suspend to RAM
Use this item to select whether to auto-detect or disable the Suspend-to-
RAM feature. Select [Auto] will enable this feature if the OS supports it.
Check Ready Bit
Use this item to enable or disable the feature Check Ready Bit.
ACPI HPET Table
Use this item to enable or disable ACPI HPET Table. The default value is
[Enabled]. Please set this option to [Enabled] if you plan to use this
motherboard to submit Windows
Copyright © 2011 NEXCOM International Co., Ltd. All Rights Reserved.
Select the highest ACPI sleep
state the system will enter when
the suspend button is pressed.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F7: Discard Changes
F9: Load UEFI Defaults
F10: Save & Exit
F12: Print Screen
ESC: Exit
® Vista TM certification.
PS/2 Keyboard Power On
Use this item to enable or disable PS/2 keyboard to turn on the system
from the power-soft-off mode.
PCI Devices Power On
Use this item to enable or disable PCI devices to turn on the system from
the power-soft-off mode.
Ring-In Power On
Use this item to enable or disable Ring-In signals to turn on the system
from the power-soft-off mode.
RTC Alarm Power On
Use this item to enable or disable RTC (Real Time Clock) to power on the
system.
USB Keyboard/Remote Power On
Use this item to enable or disable USB Keyboard/Remote to power on the
system.
USB Mouse Power On
Use this item to enable or disable USB Mouse to power on the system.
