10.3. Setting the Trace

The trace operation can be stored.
1. Tilt the joystick up or down to select "TRACE NO." on the trace
setting screen.
2. Select the trace No. to be stored from "01" through "08" by tilting
the joystick left or right.
3. Tilt the joystick up or down to select "EVENT FILL," then press
the Set key.
" " appears on the left side of " EVENT FILL," starting storage.
4. Set the trace using the joystick (Rotate and Zoom).
A series of operation is stored.
5. After trace setting completion, press the Set key.
" " on the left side of " EVENT FILL" disappears, exiting the
event setting.
6. Tilt the joystick up or down to select "SAVE," then tilt the joystick
right.
Trace setting is saved.
Trace No. automatically moves to the next Trace No.
Notes
• A maximum of about 2 minutes for the event or 99% of the event displays can be stored within one trace.
If 2 minutes have already passed before pressing the Set key, no subsequent operations can be stored.
• Operations using any key other than joystick (Pan and Zoom) cannot be stored.
• The stored content may slightly differ from the actual reproduction view on the monitor. To avoid this, select
a wider angle of view than you wish, and slowly operate camera movements during the trace operation
memory.
• It is not possible to perform trace setting in the Electronic zoom areas.
T R A C E S E T
T R A C E N O . T R A C E N O . : 0 1 0 1
T R A C E I D : T R A C E 0 1
E V E N T F I L L : 0 0 0 %
S A V E
C L E A R
E X I T
T R A C E S E T
T R A C E N O . : 0 1
T R A C E I D : T R A C E 0 1
E V E N T F I L L E V E N T F I L L : 0 0 0 %
S A V E
C L E A R
E X I T
