8.3. Setting the Tour

Sets the operation to be programmed for each tour ("1" through "8").
1. Tilt the joystick up or down to select "TOUR NO." on the tour
setting screen.
2. Select the Tour No. to be programmed from "01" through "08"
by tilting the joystick left or right.
3. Select "TOUR STEP" by tilting the joystick up or down.
4. Select the Tour Step No. to be programmed from "01" through
"60" by tilting the joystick left or right.
5. Select "PRESET NO." by tilting the joystick up or down.
6. Select the preset No. to be programmed from "BLK" or "001"
through "064" by tilting the joystick left or right.
7. Select "PAUSE TIME" by tilting the joystick up or down.
8. Select the pause time after the program has been preset from
"01" through "99" by tilting the joystick left or right.
9. Select "SPEED" by tilting the joystick up or down.
10. Select the preset speed from "010º/s" through "200º/s " (10º/s
intervals) by tilting the joystick left or right.
11. Tilt the joystick up or down to select "SAVE," then tilt the
joystick right.
Tour setting is saved.
Tour Step No. automatically moves to the next Tour Step No.
12. To further continue step setting, return to Step 3, then repeat
the same operation.
T O U R S E T
T O U R N O . T O U R N O . : 0 1
T O U R I D : T O U R 0 1
T O U R S T E P : 0 1
P R E S E T N O . : B L K
P A U S E T I M E : 0 3
S P E E D : 2 0 0 ° / S
S A V E
E X I T
T O U R S E T
T O U R N O . : 0 1
T O U R I D : T O U R 0 1
T O U R S T E P : 0 1
P R E S E T N O . P R E S E T N O . : B L K
P A U S E T I M E : 0 3
S P E E D : 2 0 0 ° / S
S A V E
E X I T
