9. Select "ADJUST" by tilting the joystick left or right, then press
the Set key.
" " appears on the left side of "ACTION."
10. Determine the masking size using the joystick, then press the
Set key.
" " on the left side of "ACTION" disappears.
Tilting the joystick left or right changes the masking size in a
horizontal direction.
Tilting the joystick up or down changes the masking size in a
vertical direction.
11. Tilt the joystick up or down to select "SAVE," then tilt the
joystick right.
Privacy masking setting is saved. Privacy No. automatically
moves to the next privacy No.
Note
The masking movement may not follow the camera's quick rotation,
allowing the masked portion to be viewed momentarily. Therefore,
set the masking size larger than needed whenever possible.
Note
The Privacy Masking function cannot be set when the camera's
vertical direction is pointing between -45° and -90°.
P R I V A C Y S E T
P R I V A C Y N O .
D I S P L A Y
A C T I O N A C T I O N
S A V E
E X I T
2°
The range that the
Privacy Masking
function can be set.
-45°
: 0 1
: O F F
: A D J U S T
Lens
-90°
