Toa C-CV14-CS Instruction Manual

Toa C-CV14-CS Instruction Manual

Ntsc & pal color camera
Hide thumbs Also See for C-CV14-CS:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual

COLOR CAMERA

Thank you for purchasing TOA's Color Camera. Please carefully follow the instructions in this manual in
order to ensure long, trouble-free use of your color camera.
INSTRUCTION MANUAL
C-CV14-CS NTSC
C-CV14-CS PAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-CV14-CS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toa C-CV14-CS

Summary of Contents for Toa C-CV14-CS

  • Page 1: Color Camera

    COLOR CAMERA Thank you for purchasing TOA’s Color Camera. Please carefully follow the instructions in this manual in order to ensure long, trouble-free use of your color camera. INSTRUCTION MANUAL C-CV14-CS NTSC C-CV14-CS PAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. SAFETY PRECAUTIONS 2. GENERAL DESCRIPTION 3. HANDLING PRECAUTIONS 4. NOMENCLATURE 5. INSTALLATION 6. CONNECTIONS 7. ADJUSTMENT 8. ABOUT THE MODE SETTING SWITCH 8.1. Adjustment Switch ... 9 8.2. Backlight Compensation Switch ... 9 8.3. Shutter Speed Switch ... 9 9.

  • Page 3: Safety Precautions

    1. SAFETY PRECAUTIONS • Before installation or use, be sure to carefully read all the instructions in this section in order to ensure long, trouble-free operation. • Be sure to follow all the precautionary instructions in this section, which contain important warnings regarding safety.

  • Page 4: General Description

    SECURITY RELATED FUNCTIONS OF THIS PRODUCT. 2. GENERAL DESCRIPTION The C-CV14-CS Color Camera is a high-resolution surveillance camera equipped with a 1/4” CCD. It is designed to operate on 24V AC or 12V DC.The CS mount permits the optional lens that is the most appropriate for each application to be selected.

  • Page 5: Nomenclature

    4. NOMENCLATURE (1) Lens connector (2) Back focal length adjustment ring fixing screw (3) Camera mount fixing screw (4) Camera mount (5) Back focal length adjustment ring (6) Power input terminal (24 V AC or 12 V DC) Note Fixing holes (10) are provided in both the top and bottom panels. (7) Iris control (8) Video output terminal (BNC) (9) Mode setting switch...

  • Page 6: Installation

    5. INSTALLATION [Ceiling mounting example] Camera mounting bracket (optional) Lock lever Pedestal Camera mount WARNING Install the unit only in a location that can structurally support the weight of the unit and the mounting bracket. Doing otherwise may result in the unit falling down and causing personal injury.

  • Page 7: Connections

    Notes • To avoid damaging the internal sections of the camera's lens mount, be sure that the lens flange is less than 5 mm thick as illustrated on the right. • C-mount lenses must be used in conjunction with the Lens Mounting Adapter CF-5 (optional).

  • Page 8: Adjustment

    7. ADJUSTMENT 1. Switch on the camera power after completing camera connections. Power is supplied to the camera. 2. Normally,set the Shutter Speed switch to "1/60"(NTSC) or "1/50"(PAL) position. Flickering of the picture may interfere with the view under fluorescent lamp in the area with power frequency of 50 Hz(NTSC) or 1/60 Hz(PAL).

  • Page 9: About The Mode Setting Switch

    8. ABOUT THE MODE SETTING SWITCH Set the Mode Setting switch for the best possible picture reproduction depending on installation conditions. IRIS VIDEO OUT 8.1. Adjustment Switch Set this switch when adjusting the lens focus.(Provides the same effect as when using the ND filter.) OFF ON Standard position : Set to OFF after lens adjustment completion.

  • Page 10: If You Think There Is A Failure: (Troubleshooting)

    9. IF YOU THINK THERE IS A FAILURE: (TROUBLESHOOTING) Symptom Camera images are • The monitor’s power switch is not not displayed on the • Cables are not correctly connected. monitor. • The BNC plug is not correctly • Power is not supplied to the •...

  • Page 11: Specifications

    300 g The specifications of this camera are subject to change without notice. • Optional Products Camera mounting bracket C-CV14-CS (NTSC) 752 (H) x 582 (V), 440,000 pixels 15.625 kHz (H), 50 Hz (V) H: 470 lines (center), V: 410 lines 3 lx (F:1.4, 350 mV)
  • Page 12 Printed in Vietnam 1 3 3 - 1 2 - 8 8 1 - 7 D...
