Initial Setting Level
Scaling upper limit
Scaling lower limit
Decimal point
Function
Setting
See
• These parameters can be used when voltage input is selected as the
input type.
• When voltage input is selected as the input type, scaling is carried out.
Set the upper limit in the "scaling upper limit" parameter and the lower
limit in the "scaling lower limit" parameter.
• The "decimal point" parameter specifies the decimal point position of
parameters (set point, etc.) whose unit is set to EU.
• Scaling upper limit, Scaling lower limit
Parameter
Scaling upper limit
Scaling lower limit
• Decimal point: Default is "0: 0 digits past decimal point"
Set value
0 0 digits past decimal point
1 1 digit past decimal point
Related parameters
"Input type" (initial setting level)
The input type must be set to analog
input.
Setting Range
Scaling lower limit +1 to 9999
-1999 to scaling upper limit -1
Setting
Section 5-5
Unit Default
None 100
None 0
Example
1234
123.4
