LevelOne Broadband Router User Guide
WAN Status
Clicking Status on the menu bar will take you to the WAN Status screen. The
screen shown will depend on whether you are using a Direct Connection or
PPPoE.
WAN Status - Direct Connection
Data
WAN Status
Physical Address
IP Address
Network Mask
Figure 11: WAN Status - Direct Connection
"Hardware" address of this device, as seen by devices
on the WAN.
The IP Address of this device, as seen by devices on
the WAN.
(This device has 2 IP Addresses; one for the local
LAN, and another for the WAN port.)
The Network Mask for the above IP Address.
26
