LevelOne Broadband Router User Guide
Data
Status
Physical Address
IP Address
Network Mask
PPPoE Link
Status
Log
Log Data
Buttons
Connect
Disconnect
Clear Log
Refresh
The "Hardware" address of this device, as seen by
other devices on the WAN.
The IP Address of this device, as seen by devices on
the WAN.
(This device has 2 IP Addresses; one for the local
LAN, and another for the WAN port.)
The Network Mask (Subnet Mask) for the IP Address
above.
This indicates whether or not the connection is
currently established.
If the connection does not exist, the Connect button
can be used to establish a connection.
If the connection currently exists, the Disconnect
button can be used to break the connection.
The Connection Log shows status messages relating
to the existing connection.
The most common messages are listed in the follow-
ing table.
If not connected, establish a connection to your ISP
If connected to your ISP, hang up the connection.
Delete all data currently in the Log. This will make it
easier to read new messages.
Contact this device and update the Log data.
28
