LevelOne FBR-1700TX User Manual page 26

Hardware
(MAC) Address
DHCP Client
(Dynamic
IP Address)
Fixed
IP Address
Buttons
Retrieve
Defaults
Save
Cancel
Note:
If using DHCP Client (Dynamic IP Address), the IP Address, Network
Mask, and Gateway fields may display the values obtained dynamically.
If your ISP asks for the Network Adapter Address,
Physical Address, Hardware Address, or MAC
Address for the PC the DSL/Cable modem is con-
nected to, provide this value.
Leave this enabled if you want your ISP to allocate an
IP Address to the FBR-1700TX upon connection.
Select this if using a fixed IP Address. If this option is
selected, the following data must be entered.
•
IP Address.
If connecting to an ISP, this is the address allo-
cated by the ISP. If connecting to another LAN,
this must be a valid address on the external LAN.
•
Network Mask
This must be compatible with the IP Address
above
•
Gateway IP Address
The address of the router or gateway, either on
the external LAN, or supplied by your ISP.
Get the default Device Name and clear the other
items. No changes are made to the configuration until
you click the Save button.
Save any data you have entered on this screen.
Remember to save before changing to another screen.
Cancel any data you have entered since the last
"Save" operation.
Configuration
23
