LevelOne Broadband Router User Guide

LAN Port

Physical Address
IP Address
Network Mask
DHCP Server
DHCP Table
IP Address
Physical Address
Status
Note:
The DHCP table will be empty unless the DHCP Server function is being
used. If not empty, this table lists the devices on the LAN which have
been allocated IP Addresses by the DHCP server function.
The "Hardware" address of this device, as seen by
other devices on the Internal LAN.
The IP Address of this device, as seen by other
devices on the Internal LAN.
The Network Mask (Subnet Mask) for the IP
Address above.
This shows the status of the DHCP Server function.
The value will be "Enabled" or "Disabled".
The IP Address which has been allocated by the
DHCP server to the other device.
The Physical Address (Hardware Address) of the
device which has been allocated a IP Address.
Possible Status values are "Leased" (the IP Address
is allocated to the device shown) or "Reserved" (the
IP Address is not available).
32
