To Delete a defined Server
- Select it from the drop-down list,
- Click "Delete"
•
To List all Servers
- Click "List All"

Configuration Data

Name
Enable
IP Address
Protocol
Internal Port
Number
External Port
Number
Enter a descriptive name to identify this Server entry.
Use this to Enable or Disable support for this Server, as
required.
The IP Address of the PC on your LAN which is running
the Server software.
Select the protocol (TCP or UDP) used by the Server.
Enter the port number used by the Server to connect to
clients.
The port number used by clients when connecting to the
Server. This is normally the same as the Internal Port
Number.
If it is different, this device will perform a "mapping" or
"translation" function, allowing the server to use one port
address, while clients use a different port address.
From the Internet, ALL Virtual Servers have the
IP Address allocated by your ISP, as shown on
the WAN Status screen.
