Configuration Program
The FBR-1700TX contains a HTTP server. This enables you to connect to it,
and configure it, using your Web Browser.
Most Browsers should work, provided they support HTML tables and forms.
Preparation
Before attempting to configure the FBR-1700TX, please ensure that:
•
Your PC can establish a physical connection to the FBR-1700TX. The
PC and the FBR-1700TX must be directly connected (using one of the
Hub ports on the FBR-1700TX) or on the same LAN segment.
•
The FBR-1700TX must be installed and powered ON.
•
If the FBR-1700TX's default IP Address (192.168.0.1) is already used by
another device, the other device must be turned OFF until the FBR-
1700TX is allocated a new IP Address during configuration.
Connecting to the FBR-1700TX
To establish a connection from your PC to the device:
1.
After installing the FBR-1700TX in your LAN, start your PC. If your PC
is already running, restart it.
2.
Start your WEB browser.
3.
In the Address box, enter "HTTP://" and the IP Address of the FBR-
1700TX, as in the following example, which uses the FBR-1700TX's de-
fault IP Address:
HTTP://192.168.0.1
4.
If you have assigned a password to the FBR-1700TX you will be
prompted for the password, as shown below. (If no password has been set,
this dialog will not appear.)
Configuration
15
