Dhcp Server - LevelOne FBR-1700TX User Manual

Data - LAN Port Screen
Internal LAN
Device IP
Address
Network Mask

DHCP Server

Operation
Start IP Ad-
dress
Finish IP
Address
IP address for the FBR-1700TX. Use the default value
of 192.168.0.1 unless the address is already in use or
your LAN is using a different IP address range. In the
latter case, enter an unused IP Address from within the
range used by your LAN.
The default value 255.255.255.0 is standard for small
(class "C") networks. For other networks, use the
Network Mask for the LAN segment to which the FBR-
1700TX is attached. i.e. the same value as the PCs on
that LAN segment.
If Enabled, the FBR-1700TX will allocate IP Ad-
dresses to PCs on your LAN. The default and
recommended value is Enabled.
If you are already using a DHCP Server, this setting
must be DISABLED, and the existing DHCP server
must be re-configured. See Chapter 5 for further
details.
The Start IP Address and Finish IP Address fields set
the values used by the DHCP server.
This range also determines the number of DHCP clients
supported. (Maximum 253.)
Configuration
19
