LevelOne Broadband Router User Guide
FBR-1700TX Features
The FBR-1700TX incorporates many advanced features, carefully designed
to provide sophisticated functions while being easy to use.
LAN Features
•
7 Port Switching Hub.
Switching Hub. Both 10BaseT and 100BaseT connections can be used
simultaneously.
•
DHCP Server Support.
vides a dynamic IP address to PCs and other devices upon request. The
FBR-1700TX can act as a DHCP Server for devices on your local LAN.
•
Multi Segment LAN Support.
ments are supported, via the FBR-1700TX's built-in static routing table.
If NAT (Network Address Translation) is disabled, the FBR-1700TX will
function as a static router.
Internet Access Features
•
Shared Internet Access.
through the FBR-1700TX, using only a single external IP Address. The
local (invalid) IP Addresses are hidden from external sources. This proc-
ess is called NAT (Network Address Translation).
•
ADSL & Cable Modem Support.
Ethernet port for connecting an ADSL or Cable Modem. All popular
ADSL and Cable Modems are supported.
•
PPPoE Support.
Ethernet), if your ISP uses this method.
•
Fixed or Dynamic IP Address.
1700TX supports both Dynamic IP Address (IP Address is allocated on
connection) and Fixed IP Address.
The FBR-1700TX incorporates a 7 port
Dynamic Host Configuration Protocol pro-
LANs containing one or more seg-
All users on the LAN can access the Internet
Connect to your ISP using PPPoE (PPP over
The FBR-1700TX has a 10BaseT
On the WAN connection, the FBR-
2
