The port-based LEDs can be cycled between three display modes: Status, Duplex, and Speed.
Pushing the mode button causes the display mode to be cycled.
Mode
Status
Duplex
Speed
Table 2: LED Display Description
©
2008 RuggedCom Inc. All rights reserved
Colour
Green (Solid)
Green (Blinking)
Off
Green (Solid)
Orange (Solid)
Off
Green (Blinking)
Green (Solid)
Orange (Solid)
Off
10
Description
Link
Activity
No link
Full-Duplex operation
Half-Duplex operation
No link
1000Mb/s
100Mb/s
10Mb/s
No link
