Next Click this button to view the next page of the address table.
View All Entry Clicking this button will allow the user to view all entries of the address table.
Clear All Entry Clicking this button will allow the user to delete all entries of the address table.

IGMP Snooping Group

This window allows the Switch's IGMP Snooping Group Table to be viewed. IGMP Snooping allows the Switch to read the
Multicast Group IP address and the corresponding MAC address from IGMP packets that pass through the Switch.
To view this window, click Monitoring > IGMP Snooping Group, as shown below:
The user may search the IGMP Snooping Group Table by VLAN name by entering it in the top left hand corner and clicking Find.
To view all entries click View All Entry.
NOTE: To configure IGMP snooping for the xStack
L2 Features folder and select IGMP Snooping. Configuration and other information
concerning IGMP snooping may be found in Section 7 of this manual under IGMP
Snooping.

MLD Snooping Group

The following window allows the user to view MLD Snooping Groups present on the Switch. MLD Snooping is an IPv6 function
comparable to IGMP Snooping for IPv4. The user may browse this table by VLAN Name present in the switch by entering that
VLAN Name in the empty field shown below, and clicking the Search button.
To view this window, click Monitoring > MLD Snooping Group, as shown below:
The user may search the MLD Snooping Group Table by VLAN name by entering it in the top left hand corner and clicking Find.
To view all entries click View All Entry.
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
Figure 7 - 30 IGMP Snooping Group Table window
Figure 7 - 31 MLD Snooping Group Table
®
DGS-3400 Series switch, go to the
